72" x .120" x 50,000# PM High Speed Blanking/ Cut-to-Length Line

Brand
PM

Model
Not Specified

Type
Cut To Length Lines

Stock #
605501

Condition
Used

Year

Request a Quote
Have one to sell?
Coil Weight 50000 pounds
Width 72 inches
Thickness .120 inches
ID 30 inches
Max OD 80 inches

Equipped With

Line Speed:  275 FPM
Sheet Length Range:  5.5" - 192"
Coil Width Range:  9" - 72"
(COMPLETE ELECTRICAL UPGRADE IN 2006)

Featuring:
Double Expandable Mandrel Uncoiler
Peeler Table
Entry Crop Shear
7 Roll Backed Up Flattener
60 HP DC Motor
PM 6-HI Precision Leveler
1.5" Work Roll Diameter
17 Work Rolls
50 HP DC Motor
Servo Feed Rolls
Down Cut Bow Type Shear
25' Exit Belt Conveyor
Stacker
End Discharge Table
*NO Digital Drives or PLC Controls
Complete Line
(REBUILT IN 1999)
