78" (2000mm) x 16mm x 35T Multi Blanking Line

Brand
Not Specified

Model
Not Specified

Stock #
604528

Condition
Used

Year

Width 78 inches
Thickness .63 inches
Coil Weight 70000 pounds

Equipped With

Thickness: 4-16mm
Max Coil Width: 2000mm
Max Coil Weight: 35 tons
Coil ID: 508mm, 610mm, 760mm
Coil OD: Max 2100mm
Cut To Length Width: 2250mm
Slitter Arbor Diameter: 400mm
Pinch Roll Diameter: 300mm 2rolls
Flattener Roll Diameter: 250mm x 9rolls
Leveler Roll Diameter: 168mm 2+15rolls
Line Direction: Right to Left

Scope of Supply:
Coil Stager
Hydraulic Coil Car
Hydraulic Discharging Machine
4-Column Hydraulic Pressing Straight Head Device
Peeler and Pinch Rolls
Flattener
Carry Over Table
Guiding Device
Trimming Unit
Edge Wire Coiler
Finish Leveler
Coding and Sizing Machine
Tailboard Pinching Mechanism
Slitting Head
Head and Tail Plate Discharging Car
Swing Pneumatic Pinching Machine
Shear
Double X Lifting Table
Discharging Car

Hydraulic System
Pneumatic System
Electric Control System
