General Specifications:
Strip Width Range: 200mm-1580mm
Strip Thickness Range: .4mm-5mm
Max Coil Weight: 30 Tons
Entry Coil ID: 508mm and 610mm
Exit Coil ID: 508mm
Entry Coil OD Range: 1000mm-2100mm
Exit Coil OD Range: 700mm-2100mm
Max Speed: 200m/min
5 Cuts of 5mm Thickness
Line Direction: Left to Right
Complete with the Following Components:
Coil Storage Holders
Entry Coil Car
Uncoiler
Motorized Recoiler for PVC and Paper
Pinch Rolls with Straightener
Entry Crop Shear
PVC Applicator
Slitter Head
Four Arm Tooling Capstan
Two Scrap Winders
Exit Pinch Roll
Looping Pit with Entry and Exit Tables
Tension Stand
Exit Crop Shear
Recoiler
Exit Coil Car with Coil Keepers
Two Arm Exit Turnstile
